6-Pin Hirose Cable


  • 6-Pin Hirose Cable with Two Male Connectors
  • 10 ft (3 m) Long
  • Compatible with the TC200 Temperature Controller as well as
    Thorlabs’ Single-Blade Beam Shutters and Controller

TC200CAB10

Related Items


Please Wait
TC200CAB10 Drawing
Male Hirose Connector
TC200CAB10 Pin Diagram
Wire Diagram

Features

  • 6-Pin, Male-to-Male Hirose Connector Cable
  • Compatible with Several Thorlabs Products
  • Cut and Expose Wire for Custom Applications

The TC200CAB10 is a 6-pin, male-to-male Hirose connector cable. This 10-foot-long cable is compatible with our TC200 temperature controller, SH05 and SH1 beam shutters, and SC10 shutter controller. The wires in this cable cross as seen in the drawing to the right. This is not a straight-through cable.

This Hirose connector cable can also be cut to any length, leaving one connectorized end and one bare end. The colored wire diagram above shows the relationship between the six colored wires and the pins in the connector, allowing the cut cable to be incorporated into a variety of custom applications.



Electrical Specifications
Conductor
Number of Conductors6
Conductor Gauge26 AWG
Capacitance85.306 pF/m
Propagation Velocity60%a
Conductor Resistance122.381 Ω/km
Max. Operating Voltage300 VRMS
Current per Conductor (Max)1.2 A
Operating Temperature-20 to 80 °C
Connector
Contact Resistance (1 A, DC)10 mΩ
Insulation Resistance1000 MΩ
Voltage (Max)140 VDC
Current (Max)2 A
Operating Temperature-25 to 85 °C

a. The signal through the cable travels at 60% the speed of light

Physical Specifications
Connectors6-Pin, Male Hirose
Length10 Feet (3 m)
Insulating MaterialPVC - Polyvinyl Chloride
Insulation Thickness0.381 mm
Outer Jacket Thickness0.940 mm
Bend Radius (Min)57.150 mm

Posted Comments:
joe_bell  (posted 2017-02-06 08:30:46.527)
The TC200CAB10 is a 6-pin Male-Male Hirose connector cable, 10' long. Do you guys have access to a longer cable (20 feet), or a female-male cable I could use as an extender? Thanks, Joe
tfrisch  (posted 2017-02-14 02:04:13.0)
Hello, thank you for contacting Thorlabs. I will reach out to you directly about this custom cable.
huilinghan  (posted 2014-02-24 16:02:37.49)
TC200CAB10 is 6-Pin, Male-Male Hirose Connector Cable, 10' Long I would like to purchase a 6-Pin, Female-Female Hirose Connector Cable, 10' Long. Where an I find it? thanks.
jlow  (posted 2014-02-25 04:34:44.0)
Response from Jeremy at Thorlabs: I will contact with about getting the female Hirose cable.
